Magnetic Particle Inspection (MPI) in Chennai
Fast, sensitive surface and near-surface flaw detection in ferromagnetic materials using visible black and fluorescent magnetic media in Chennai.
Certified Level II inspector performing Magnetic Particle Testing. LEVEL II / III
Overview of Magnetic Particle Testing (MPT)
Detailed testing capabilities provided by NP Technical Services Pvt. Ltd. from our West Tambaram, Chennai facility.
Magnetic Particle Testing (MPT/MPI) is an established non-destructive testing method designed to locate surface-breaking and slight sub-surface discontinuities in ferromagnetic materials such as carbon steel, low-alloy steel, and cast irons. When the component is magnetized, cracks and discontinuities create magnetic flux leakage fields that attract magnetic iron particles, revealing sharp visual flaw indications under visible light or UV illumination.
An electromagnetic yoke, coil, or stationary bench induces a magnetic field into the ferromagnetic test specimen. Finely divided magnetic particles coated with pigments or fluorescent dyes are applied across the test surface. Discontinuities perpendicular to magnetic flux lines disrupt the field, causing leakage that traps particles and forms distinctive defect indications for certified Level II evaluation.
Certified Technical Execution Across Tamil Nadu
Every Magnetic Particle Testing assignment is executed adhering to approved written procedures, client inspection test plans (ITP), and certified Level II & Level III oversight.
Magnetic Particle Testing Techniques Deployed
Calibrated inspection procedures tailored for specific geometries, welded joint configurations, and material alloys.
Electromagnetic AC/DC Yoke Testing
Portable articulating yokes for fast on-site inspection of structural weldments, pressure vessel seams, and field fabrication joints.
Fluorescent Wet Continuous Method (WFMT)
High-sensitivity darkroom examination under ultraviolet (UV-A) black light for precision automotive forgings, machined aerospace parts, and critical castings.
Visible Dry Powder & Black Magnetic Ink
High-contrast white background lacquer with black magnetic ink for in-situ site surveys, pipe girth welds, and lifting hooks.
Bench Unit Multi-Directional Magnetization
Stationary production bench inspection with circular and longitudinal shot coils for high-throughput batch manufacturing quality control.
Primary Inspection Applications
Magnetic Particle Testing is deployed across raw stock, fabricated structures, and operational plant equipment.
- Full-penetration welded seams & heat-affected zones (HAZ)
- Forged crankshafts, gears, turbine components & connecting rods
- Machined high-tensile fasteners, bolts & structural pins
- In-service crane hooks, lifting lugs & mobile equipment shackles
- Steel foundry castings for shrinkage cracks, tears & inclusions
Equipment & Standards Used
All instruments and consumables are verified and calibrated prior to each inspection shift.
- Articulating AC/DC Portable Electromagnetic Yokes (NP Tech manufactured)
- Stationary Wet Horizontal MPI Production Bench Units (1500A - 4000A)
- Calibrated Pie Gauges, Burmah-Castrol Strips & Field Indicators
- UV-A LED Inspection Lamps (365 nm peak wavelength)
- Centrifuge settling test tubes & ASTM D96 suspension verification
Magnetic Particle Testing FAQs
Common questions regarding magnetic particle testing procedures, technician qualifications, and on-site testing in Chennai.
No. MPT requires ferromagnetic materials such as carbon steel and cast irons. For austenitic stainless steel, aluminum, or brass, Liquid Penetrant Testing (LPT) or Eddy Current Testing (ECT) is used instead.
AC magnetization concentrates the magnetic field along the outer skin of the component, providing maximum sensitivity for shallow surface cracks. DC magnetization penetrates deeper into the section, aiding the detection of sub-surface discontinuities.
Yes. NP Tech mobilizes certified Level II inspectors equipped with portable electromagnetic yokes, black/white contrast consumables, and calibrated field indicators for rapid on-site testing across Chennai and Tamil Nadu.
Related Non-Destructive Testing Methods
Combine Magnetic Particle Testing with complementary surface or volumetric testing services for complete quality assurance.
Ultrasonic Testing
Ultrasonic Testing & Thickness Gauging (UT)
High-frequency acoustic wave inspection for detecting internal volumetric flaws, laminar discontinuities, and accurate residual wall thickness measurement in Chennai.
Liquid Penetrant Testing
Liquid / Dye Penetrant Testing (DPT/LPT)
Highly sensitive capillary method for revealing surface-breaking cracks, porosity, and laps in non-porous metals and alloys in Chennai.
Visual Testing
Visual Inspection & Examination (VT)
Primary baseline inspection evaluating weld dimensions, surface condition, alignment, fit-up, and mechanical damage in Chennai.
Request Magnetic Particle Testing in Chennai
Submit component drawings, weld specifications, or project turnaround schedules for prompt review by our certified Level II / Level III inspectors.
